#10 HI-LO
Levi’s Hi-Lo screws are some of the best in the industry. They are sharper, drill better, and the cut point is true. The paint stays on when installing and builders prefer Levi’s “true” sizing and Hi-Lo threading for better holding power and easy installation. Choose from 40 plus in-stock colors that can ship immediately or specifically color match and still receive timely shipping.
• #10 Hi-Lo screw, type 17 point
• Mechanical galvanized
• Hi-Lo threads
• Galvanized EPDM washer 1/2″ OD
• Fastens metal to wood
Previous
Next
| PART# | DESCRIPTION | HEAD STYLE | DRILL PT | PCS/BOX | LBS/BOX |
| 123ST | #12 - 14 X 3/4" Stitch | 1/4" Hex | Sharp Point | 3,000 | 25.9 |
| 101HL | #10 x 1" | 1/4" Hex | T-17 | 3,000 | 26.6 |
| 10112HL | #10 x 1-1/2" | 1/4" Hex | T-17 | 2,500 | 27.8 |
| 102HL | #10 x 2" | 1/4" Hex | T-17 | 2,000 | 26.4 |
| 10212HL | #10 x 2-1/2" | 1/4" Hex | T-17 | 1,500 | 23.7 |
| 103HL | #10 x 3" | 1/4" Hex | T-17 | 1,000 | 18.3 |
| 104HL | #10 x 4" | 1/4" Hex | T-17 | 500 | 11.8 |
| SUBSTRATE | PENETRATION | PULL-OUT STRENGTH |
| 3/4" Ply | Full | 530 |
| 1/2" Ply | Full | 305 |
| 7/16" OSB | Full | 158 |
| 2 x Yellow Pine | 1" | 986 |
| 2 x Spruce Pine Fir | 1" | 1,023 |
| 2 x Spruce Pine Fir | 1 - 1/2" | 1,379 |
| SHEAR | TENSILE | TORSIONAL |
| 1,900 | 2,736 | 60 |
| SUBSTRATE | GAUGE | THICKNESS | PULL-OVER STRENGTH |
| AZ55 Galvalume | 29 | .014 | 415 |
| AZ55 Galvalume | 26 | .018 | 560 |
| AZ55 Galvalume | 24 | .024 | 717 |
The Fastgrip™ #10 Hi-Lo MINI-DRILLER™ has all of the specs that make the Fastgrip™ #10 Hi-Lo the go-to fastener, but with the added MINI-DRILLER™ point. The MINI-DRILLER™ makes easy work of driving through metal panels, while the Hi-Lo thread provides superior pull-out strength in metal to wood applications.
• Faster start time
• Increased performance when drilling through two layers of metal
• Reduces trapped steel shavings
• Mechanical galvanized
• Hi-Lo threads
• 1/2″ galvanized EPDM washer
Previous
Next
| PART# | DESCRIPTION | HEAD STYLE | Drill PT | PCS/BOX | LBS/BOX |
| 101MD | #10 x 1" | 1/4" Hex | Reduced Point | 3,000 | 26.8 |
| 10112MD | #10 x 1-1/2" | 1/4" Hex | Reduced Point | 2,500 | 27.9 |
| 102MD | #10 x 2" | 1/4" Hex | Reduced Point | 2,000 | 27.3 |
| 10212MD | #10 x 2-1/2" | 1/4" Hex | Reduced Point | 1,500 | 23.5 |
| 103MD | #10 x 3" | 1/4" Hex | Reduced Point | 1,000 | 19.0 |
| SUBSTRATE | PENETRATION | PULL-OUT STRENGTH |
| 3/4" Ply | Full | 525 |
| 1/2" Ply | Full | 280 |
| 7/16" OSB | Full | 217 |
| 2 x Yellow Pine | 1" | 850 |
| 2 x Spruce Pine Fir | 1" | 787 |
| 2 x Spruce Pine Fir | 1 - 1/2" | 1,285 |
| SHEAR | TENSILE | TORSIONAL |
| 1,750 | 2,486 | 80 |
| SUBSTRATE | GAUGE | THICKNESS | PULL-OVER STRENGTH |
| AZ55 Galvalume | 29 | .014 | 398 |
| AZ55 Galvalume | 26 | .018 | 667 |
| AZ55 Galvalume | 24 | .024 | 767 |
#14
Ensure superior holding power for OSB and plywood construction with the mechanical galvanized #14 roofing screw. Great pull out resistance is this fastener’s strength. Tight sealing EPDM washer and type 17 point. Levi’s can quick ship so your next project remains on time.
• Mechanical galvanized
• Galvanized EPDM washer 14MM OD
• Fastens metal to wood
• Use for OSB and other plywood
• Great pull-out resistance
Previous
Next
| PART# | DESCRIPTION | HEAD STYLE | DRILL PT | PCS/BOX | LBS/BOX |
| 141FG | #14 x 1" | 5/16" Hex | T-17 | 2,000 | 28.6 |
| 14112FG | #14 x 1-1/2" | 5/16" Hex | T-17 | 1,500 | 27.8 |
| 142FG | #4 x 2" | 5/16" Hex | T-17 | 1,000 | 23.4 |
| 14212FG | #14 x 2-1/2" | 5/16" Hex | T-17 | 500 | 14.2 |
| SUBSTRATE | PENETRATION | PULL-OUT STRENGTH |
| 3/4" Ply | Full | 621 |
| 1/2" Ply | Full | 449 |
| 7/16" OSB | Full | 209 |
| 2 x Yellow Pine | 1" | 992 |
| 2 x Spruce Pine Fir | 1" | 1,294 |
| 2 x Spruce Pine Fir | 1 - 1/2" | 1,597 |
| SHEAR | TENSILE | TORSIONAL |
| 2,980 | 4,492 | 175 |
| SUBSTRATE | GAUGE | THICKNESS | PULL-OVER STRENGTH |
| AZ55 Galvalume | 29 | .014 | 535 |
| AZ55 Galvalume | 26 | .018 | 743 |
| AZ55 Galvalume | 24 | .024 | 1,052 |
#9 Stainless Steel
The stainless steel Fastgrip™ series of screws does not compromise on the true size of its aluminum 1/2″ diameter washer. Available in 40 plus quick ship colors, the Fastgrip™ easily drills through aluminum panels and is prepared to handle tough installation conditions. The Fastgrip™ stainless steel is backed by Levi’s 50 year warranty.
• 300 series stainless steel
• Aluminum EPDM washer 1/2″ OD
• Fastens metal to wood
• Easily drills through aluminum panels
Previous
Next
| PART # | DESCRIPTION | HEAD STYLE | DRILL PT | PCS/BOX | LBS/BOX |
| 91SS | #9 x 1" | 1/4" Hex | Sharp Point | 3,000 | 24.2 |
| 9114SS | #9 x 1-1/4" | 1/4" Hex | Sharp Point | 2,500 | 22.7 |
| 9112SS | #9 x 1-1/2" | 1/4" Hex | Sharp Point | 2,500 | 26.1 |
| 92SS | #9 x 2" | 1/4" Hex | Sharp Point | 2,000 | 24.7 |
| 9212SS | #9 x 2-1/2" | 1/4" Hex | Sharp Point | 1,500 | 22.3 |
| 93SS | #9 x 3" | 1/4" Hex | Sharp Point | 1,000 | 17.5 |
| SUBSTRATE | PENETRATION | PULL-OUT STRENGTH |
| 3/4" Ply | Full | 465 |
| 1/2" Ply | Full | 327 |
| 7/16" OSB | Full | 180 |
| 2 x Yellow Pine | 1" | 894 |
| 2 x Spruce Pine Fir | 1" | 692 |
| 2 x Spruce Pine Fir | 1 - 1/2" | 1,264 |
| SHEAR | TENSILE | TORSIONAL |
| 1,280 | 1,455 | 52 |
| SUBSTRATE | GAUGE | THICKNESS | PULL-OVER STRENGTH |
| AZ55 Galvalume | 29 | .014 | 411 |
| AZ55 Galvalume | 26 | .018 | 567 |
| AZ55 Galvalume | 24 | .024 | 788 |
