Metal Grip Cupped-Head
On your next steel project, use our Cupped-Head screw from the Metalgrip family to provide a superior grip. An EPDM washer and a cupped head are features of the Metalgrip Cupped Hex Head Screw. Use the mechanically galvanized self-drill point #3 for metal-to-metal applications. Available in 6 different sizes.
• 5/16 Cupped Hex Head
• EPDM Washer
• 1022 Carbon Steel
• Mechanical Galvanized
• Self-Drilling #3
Previous
Next
| PART # | DESCRIPTION | HEAD STYLE | Drill PT | PCS/BOX | LBS/BOX |
| 141478CH | #14 - 1/4" x 7/8" Stitch | 5/16" Cupped Hex | #3 | 2,500 | 36.0 |
| 121434CH | #12 x 3/4" | 5/16" Cupped Hex | #3 | 2,500 | 31.1 |
| 12141CH | #12 x 1" | 5/16" Cupped Hex | #3 | 2,500 | 34.3 |
| 121411CH | #12 x 1 - 1/4" | 5/16" Cupped Hex | #3 | 2,500 | 38.5 |
| 1214112CH | #12 x 1 - 1/2" | 5/16" Cupped Hex | #3 | 2,000 | 34.7 |
| 12142CH | #12 x 2" | 5/16" Cupped Hex | #3 | 1,500 | 30.6 |
